| Amplification Type |
Passive |
| Crossover Type |
2-Way |
| Enclosure type |
Bass Reflex |
| Frequency Range (+/-3 dB)[Hz] |
40 - 32000 |
| Frequency Range (-6dB)[Hz] |
- |
| Maximum SPL [dB] |
- |
| Sensitivity (2,83 V/1 m)[dB] |
89 |
| Nominal Impedance (Ohms) |
8 |
| THD (Total Harmonic Distortion) |
- |
| Recommended Amplifier Power [W] |
175 |
| Crossover Frequency [Hz] |
- |
| Bass Reflex Tuning Frequency [Hz] |
- |
| Driver Units |
Tweeter: 1 x 28mm AE custom fabric dome
Mid/Bass Drivers: 2 x 110mm anodised aluminium cone
|
| Connectivity |
Wired |
| Inputs |
Single Wire |
| Outputs |
- |
| Magnetic Shielding |
No |
