Elac BS 73

Quick Jump

Brand, Model and Release Date

Information about the brand, model release date.

Manufacturer Elac
Model BS 73
Release Date 2014
Amazon Rating
Price

Technical Specs

Technical characteristics of the speakers.

Amplification Type Passive
Crossover Type 2-Way
Enclosure type Bass Reflex
Frequency Range (+/-3 dB)[Hz] 45 - 28000
Frequency Range (-6dB)[Hz] -
Maximum SPL [dB] -
Sensitivity (2,83 V/1 m)[dB] 87.5
Nominal Impedance (Ohms) 4
THD (Total Harmonic Distortion) -
Recommended Amplifier Power [W] 20-120
Crossover Frequency [Hz] 2800
Bass Reflex Tuning Frequency [Hz] -
Driver Units

Tweeter: 1 × 25 mm dome
Mid/Bass Drivers: 1 × 150 mm cone

Connectivity Wired
Inputs Single Wire
Outputs -
Magnetic Shielding No

Placements and Distances

Where and how to put them.

Form Factor Shelf, Stand
Distance from Wall [cm] 15

Dimensions and Weight

Speaker dimensions and weight without stands.

Length ~ 6,69 in
~152.4 mm
~15.24 cm
Width ~11.14 in
~282.96 mm
~28.3 cm
Height ~11.18 in
~283.97 mm
~28.4 cm
Weight ~25.8 lb
~11702.68 g
~11.7 kg
Shipping Weight ~25.8 lb
~11702.68 g
~11.7 kg

Colors and Accessories

List of available colors and optional accessories.

Colors
  • Black Matt
  • White Matt
Accessories
  • LS 70 II Stand
  • LS 30 Stand
Detachable Grilles No

Price and Warranty

Satisfaction is (not) guaranteed.

Warranty 3 Years
Manufacturer URL https://www.elac.com
